Arc-a
.13.56 MHz: ISO14443 A and B, ISO18092
MIFARE® Ultralight® & Ultralight® C, MIFARE® Classic & Classic EV1, MIFARE® DESFire® 256, EV1, EV2 & EV3, NFC (HCE)
Key features
Operating frequency / standards
13.56 MHz: ISO14443 A and B, ISO18092
Compatible identifiers
MIFARE® Ultralight® & Ultralight® C, MIFARE® Classic & Classic EV1, MIFARE®, DESFire® 256, EV1, EV2 & EV3, NFC (HCE)
Functions
Protocol controlled (ID write/read, feedback)
Communication interface / protocol
SSCP® v2 high-security communication protocol (RS485)
Reading distance
Up to 6 cm MIFARE® DESFire® EV2 card
Visual feedback
2 RGB LEDs - 360 colors, adjustable via software
Audio feedback
Built-in buzzer
Power consumption / Supply
130 mA/12 VDC maximum / 7 VDC - 28 VDC
Connection
Detachable terminal block
Enclosure material
ABS-PC UL-V0 (black) / ASA-PC-UL-V0 UV (white)
Dimensions (H x W x D)
106.6 x 80 x 25.7 mm
Operating temperature
- 30°C to + 70°C
Tamper switch
Accelerometer-based tamper sensor
IP and mechanical protection
IP65 level - EN 61086 standard compliant protective coating provided – weather-, water- and dust-resistant / Humidity: 0 - 95% / IK10 rated vandal-proof, reinforced enclosure
Installation
Wall-mountable, suitable for all types of surfaces, including metal.
Certifications
CE (Europe), FCC (USA), IC (Canada), UKCA (United Kingdom) and UL
Manufacturer marking
ARC-W33-A/PH5-7AD/y (where y is the enclosure color (1: black - 2: white))
